Hardened steel tube cradle. Steel fuel tank with incorporated fuel gauge. Locking fold-down handles and wheel kit. Low-oil shutdown. Hour meter with maintenance resets. AC rated output, 5 kW/5000 W, AC maximum output of 6.25 kW/6250 W, Voltage of 120/240 VAC, AC frequency of 60 Hz, 120 VAC amperage rated 41.6/Max 52.1, 240 VAC amperage rated 20.8/Max 26, engine type and displacement, OHV single cylinder 389 CC, oil capacity of 1.1 qt (1.16 L), low oil shutdown, fuel capacity of 6.6 gal (24.98 L), run rime at 1/2 load – 10 hrs, Dimensions 33-1/2 in L x 26-1/2 in W x 27-1/2 in H. Unit weight of 180 lb (81.6 kg)
|
Starting System
|
Recoil Start |
|
Engine RPM
|
3600 RPM |
|
Cast Iron Sleeve
|
Yes |
|
Voltage
|
120/240 Single-Phase |
|
Fuel Type
|
Gasoline |
|
Frequency
|
60 Hertz |
|
Alternator
|
Brush |
|
Auto Voltage Regulation
|
Yes |
|
Rated Amps
|
23 Amps @ 240 Volts (Single Phase) |
|
Portability Kit
|
Never Flat |
|
Tank Size
|
7.2 Gallons |
|
Run Time (50% Load)
|
10 Hours |
|
Fuel Tank Material
|
Metal |
|
Fuel Gauge
|
Yes |
|
Idle Control
|
No |
|
Hour Meter
|
Yes |
|
Voltage Meter
|
No |
|
Lifting Eye
|
No |
|
Assembly Required
|
Yes |
|
Dimensions
|
27.25″L x 27″W x 25″H |
|
Marque
|
Generac |
